調整杭

調整杭はさまざまな土壌に広く適用できる。特に傾斜地に合う。

  • 製品の起源:

    China
  • 色:

    Nature, or can be customized
  • 出荷港:

    Xiamen
  • ブランド:

    Wintop
  • モデル:

    KT-0001
  • 製品の詳細

調整杭


製品説明

調整杭は特に傾斜地の現場に適している。

杭本体は脱脂除錆処理を行い、その後はめっき槽に浸し亜鉛メッキという表面処理をする。この表面処理で杭の防蝕能力が高くなれる。


仕様


技術的パラメータ

設置場所 地下
風荷重 60m / s(216kmh / 133mph)
積雪量 1 .4kn/m²
設計基準 JIS C 8955-2017
杭類材質 Q235(亜鉛メッキ)
杭色 シルバ
保証期間/使用期間 10年/20年

写真
